Compact RGB-D Structured Light sensor that optimized for Short-Range & High-Accuracy!

  • Compact size for embedded integration
    • Two for factors: Module (LIPSedge L210u) & w/ Enclosure (LIPSedge L215u)
  • High-accuracy & optimized for short-range applications
    • Accuracy: Up to 0.3% @ 100cm accuracy with depth resolution 1280*800
    • Featuring global shutter
    • Great for 3D scan, 3D facial recognition, 3D measurement & optical inspection
  • Support both indoor & outdoor use
    • Featuring VCSEL @ 940nm with sunlight resistance up to 80K Lux
  • USB plug & play to a host PC
  • Industrial framework support: OpenNI, OpenCV & ROS
  • Cross-platform OS support on Windows & Linux
  • Solution Ready Package from LIPS
    • LIPSMetric Handheld Dimensioning Camera Kit​

Product Highlights

  • Structured Light Technology :
    • Small form factor / L x W x H: 54 x 25 x 11.3 mm
    • FoV 50° x 74° x 84° / Range 0.3 ~ 1 m
    • Depth resolution 1280*800
    • Indoor & outdoor use / Featuring VCSEL @ 940nm
  • Applications :
    • 3D scan, 3D facial recognition & 3D measurement
Depth Technology Structured Light
Depth Z Accuracy 0.3% @ 100cm
Depth Max. Working Distance 1.2 m
Depth Min. Working Distance 0.4 m
Depth Frame Rate (USB Output) 1280x800@6fps, 640x480@25fps
Depth Shutter Type Global Shutter
Depth FoV (H x V) 50.7° x 74.2° (+/-2°)
RGB Resolution 1280x800/6fps (YUV)
640x480/25fps (YUV)
RGB FoV (H x V) H:45.89°@UXGA, 38.86°@720p, 45.89°@VGA
V: 58.89°
RGB Shutter Type Rolling Shutter
Illumination Type Infared
Illumination Wavelength 940 nm
Illuminating Component Vertical-cavity surface-emitting laser (VCSEL)
Dimension (mm) 63.0 x 30.2 x 17.0mm
Weight(g) 85 g (approximately)
Ambient Temperature 0 ~ 40˚C
Storage Temperature -20 ~ 60˚C
Power USB Power-in, DC 5V/1A
Output Interface Micro USB (USB 2.0)
SDK Multiple Frameworks supported: OpenNI, NVIDIA Isaac, ROS
OS Windows 10
Ubuntu 16.04 / 18.04 LTS / 20.04 / 22.04 LTS
Environment Indoor
